SPECIFICATION
Model | Free Air Displacemant | Motor | Vacuum when measured on Mc Leod Guage | ||||
Lts/min | CFM | M3/H | HP | RPM | Ultimate m bar | With GB Open m bar | |
SR 50 | 50 | 1.77 | 3 | 0.25 | 2880 | 2 X 10-2 | - |
SR 100 | 100 | 3.53 | 6 | 0.33 | 2880 | 2 X 10-2 | - |
SR 150 | 150 | 5.31 | 9 | 0.33 | 1440 | 1 X 10-3 | 5 X 10-2 |
SR 250 | 250 | 8.85 | 15 | 0.50 | 1440 | 1 X 10-3 | 5 X 10-2 |
SR 350 | 350 | 12.4 | 21 | 0.75 | 1440 | 1 X 10-3 | 5 X 10-2 |
SR 500 | 500 | 17.7 | 30 | 1.0 | 1440 | 1 X 10-3 | 5 X 10-2 |
SR 1000-S | 1000 | 35.4 | 60 | 2.0 | M-1440 ------P-640 | 2 X 10-2 | 1 X 10-1 |
SR 1000 | 1000 | 35.4 | 60 | 2.0 | 1440 | 1 X 10-3 | 5 X 10-2 |
SR 1500 | 1500 | 53.1 | 90 | 3.0 | 1440 | 1 X 10-3 | 5 X 10-2 |
SR 2000 | 2000 | 70.8 | 120 | 3.0 | 1440 | 1 X 10-3 | 5 X 10-2 |
SR 400-S | 4000 | 141.6 | 240 | 5.0 | M-1440 ------P-640 | 2 X 10-2 | 1 X 10-2 |
Model | Specification | Dimension Details in mm | |||||||
Oil Capacity | Suction Port | Weight |
|
| |||||
Lts |
|
| A | B | C | D | E | F | |
SR 50 | 0.4 | 3/8” | 12 | - | - | 160 | 135 | 355 | 160 |
SR 100 | 0.6 | 1/2" | 15 | - | - | 168 | 135 | 380 | 185 |
SR 150 | 1.0 | KF25 | 33 | 345 | 140 | 225 | 190 | 510 | 210 |
SR 250 | 1.1 | KF25 | 35 | 345 | 140 | 255 | 190 | 525 | 225 |
SR 350 | 2.2 | KF25 | 45 | 345 | 160 | 275 | 210 | 590 | 290 |
SR 500 | 3.4 | KF25 | 58 | 510 | 170 | 305 | 240 | 670 | 330 |
SR 1000-S | 1.5 | KF40 | 117 | 545 | 226 | 530 | 350 | 585 | 215 |
SR 1000 | 5.0 | KF40 | 105 | 510 | 235 | 405 | 290 | 805 | 270 |
SR 1500 | 7.0 | KF50 | 160 | 700 | 284 | 415 | 395 | 940 | 320 |
SR 2000 | 7.0 | KF50 | 167 | 700 | 284 | 415 | 395 | 940 | 320 |
SR 400-S | 7.0 | 2.5” | 260 | 675 | 370 | 1020 | 500 | 735 | 318 |
